Bench Lathe Machine BM-1440

The BM-1440 Bench Lathe Machine is a high-performance precision lathe designed for industrial and workshop applications. Built with high-grade castings and hardened bedways, it ensures durability, stability, and accurate machining.

With a 14” swing and 40” between centers, this machine is ideal for fabrication shops, maintenance work, and precision turning operations.

Key Features

• Heavy-duty construction with high-grade cast iron
• Induction hardened and ground V-way bed
• Gap bed design for larger diameter workpieces
• D1-4 camlock spindle for secure operation
• Wide range of threading capabilities (metric & inch)
• Smooth feed system with safety interlock

---

Technical Specifications

Capacity

• Swing over bed: 355 mm (14”)
• Swing over carriage: 220 mm
• Swing over gap: 500 mm
• Distance between centers: 1000 mm (40”)

Spindle

• Spindle bore: 38 mm
• Spindle taper: MT5
• Spindle speeds: 8 steps
• Speed range: 70 – 2000 RPM
• Spindle nose: D1-4

Threading & Feeds

• Metric threads: 0.4 – 7 mm (26 types)
• Inch threads: 4 – 56 TPI (34 types)
• Longitudinal feeds: 0.052 – 1.392 mm/rev
• Cross feeds: 0.014 – 0.38 mm/rev

Travels

• Saddle travel: 1000 mm
• Cross travel: 170 mm
• Compound travel: 74 mm

Tailstock

• Quill travel: 95 mm
• Taper: MT3

Power

• Main motor: 1.5 kW (2 HP)
• Coolant pump: 0.04 kW

---

Standard Accessories

• 3-jaw chuck
• 4-jaw chuck
• Stand base
• Dead centers
• Change gears
• Steady rest
• Follow rest
• Tool kit
• Oil gun
• Foot brake

---

Optional Accessories

• Live center
• Face plate
• DRO (Digital Readout)
• Chuck guard
• Tool post guard
• Lead screw cover
• Taper turning attachment

---

Machine Size & Weight

• Machine size: 1920 × 760 × 760 mm
• Machine weight: 510 / 565 kg
• Stand weight: 70 / 75 kg
