G.WEIKE LF0660 3kW Enclosed Fiber Laser Cutting Machine
The G.WEIKE LF0660 is a high-precision 3,000W enclosed fiber laser cutting machine designed for precision metal cutting applications. It provides a 600 × 600mm processing area, up to 40 m/min maximum moving speed, 0.5G acceleration, and enclosed laser protection. The machine features a Gweike aviation aluminum gantry, TBI ball screws, Raytools laser head, CYPCUT control system, and Hanli water chiller.
Key Features
- 3,000W fiber laser power
- 600 × 600mm maximum processing range
- Fully enclosed laser protection
- 40 m/min maximum X/Y moving speed
- 0.5G maximum acceleration
- ±0.03mm X/Y positioning accuracy
- ±0.02mm X/Y repeat positioning accuracy
- 150kg working platform load
- 3rd-generation aviation aluminum beam
- Dual-rail and dual-driver design
- TBI grinding ball screw
- Raytools laser head
- CYPCUT control system
- Hanli water chiller
- HP industrial computer
- Designed for high-precision metal fabrication
Technical Specifications
| Specification | LF0660 3kW |
|---|---|
| Manufacturer | G.Weike Tech Co., Ltd |
| Model | LF0660 |
| Machine Type | Fiber Laser Cutting Machine |
| Laser Power | 3000W / 3kW |
| Maximum Processing Range | 600 × 600 mm |
| X-Axis Travel | 600 mm |
| Y-Axis Travel | 600 mm |
| Z-Axis Travel | 40–60 mm |
| X/Y Positioning Accuracy | ±0.03 mm |
| X/Y Repeat Positioning Accuracy | ±0.02 mm |
| Maximum X/Y Moving Speed | 40 m/min |
| Maximum Acceleration | 0.5G |
| Working Platform Load | 150 kg |
| Enclosed Laser Protection | Yes |
| Machine Dimensions | 1822 × 2152 × 1908.6 mm |
| Machine Weight | 1000 kg |
| HS Code | 845611 |
Cutting Capacity / Parameters
- Carbon steel
- Stainless steel
- Aluminum alloy
- Brass
Included With the Machine
- 3kW LF0660 machine
- 50kVA frequency converter: Three-phase 208V or 480V input, Three-phase 380V output
- 15kW air compressor
- Two-year consumable spare-parts package
- Two-year service and maintenance
- Free installation training
Machine Advantages
Enclosed Safety Design
The machine uses a fully enclosed design with protective viewing glass and smoke filtration.
Dual Rail & Dual Driver Design
The dual-rail and dual-driver configuration is designed to maintain straightness and stability during high-speed cutting.
3rd Generation Aviation Aluminum Beam
The machine uses a lightweight aviation aluminum beam designed for high-speed operation.
High Precision Drive System
The machine incorporates TBI grinding ball screws and high-precision motion components.
Packaging & Shipping
Packing size: 2360 × 1950 × 2130 mm
Gross weight: 3000 kg
